2.2 Before commissioning starts
Before commissioning the ASC-system the commissioning engineer must have an overview of the IP and ID plan, and an overview
of the power source data.
2.2.1 IP and ID plan
It is necessary to know all IDs and IP addresses of the plant. Below is an example. Please create a suitable IP plan in Excel so this
is ready before commissioning.
These parameters are needed for the commissioning:
• Device
• IP address
• Modbus ID, monitoring
• Modbus ID, control
• Baud rate
Table 2.1
Example of selected communication data for commissioning
Device IP address Modbus ID, monitoring Modbus ID, control Baud rate
ASC - 10 - 19200
ADFWEB HD67510 172.170.10.2 0 19200
-
Inverter #1 172.170.10.10 10 126
Inverter #2 172.170.10.11 11 126
Inverter #3 172.170.10.12 12 126
Inverter #4 172.170.10.13 13 126
Inverter #5 172.170.10.14 14 126
Inverter #6 172.170.10.15 15 126
Inverter #7 172.170.10.16 16 126
Inverter #8 172.170.10.17 17 126
Inverter #9 172.170.10.18 18 126
DPM - MIC 4002
(mains)
- 1 19200
DPM - MIC 4002 (generator#1) - 2 19200
