15. Operating modes
All modes are described in the designer’s reference handbook of the ASC and the AGC in more details.
15.1 Stand-alone system
In a stand-alone system, the requested mode is adjusted in the menu 6071.
Parameter Range Menu group Notes
6071
Island mode
Fixed power
Mains power export
Power management
6070
A stand-alone system can only run in Island mode, Fixed power, or mains power
export.
Set points off-grid
In off-grid mode, the set point will be as high as possible but will be curtailing the PV in order to keep the genset minimum load.
There are two different min. load settings in case you have different engine types.
COMMISSIONING GUIDELINES 4189341077D EN Page 48 of 58
