Device IP address Modbus ID, monitoring Modbus ID, control Baud rate
DPM - MIC 4002 (generator#2) - 3 19200
DPM - MIC 4002 (generator#3) - 4 19200
Table 2.2 Menus for Ethernet connection
Connection Function Associated menus
Ethernet ASC device IP number
9000
(9002 = IP/Subnet mask)
(9003 = Gateway)
2.2.2 Power source data
The power source data must be available before the commissioning starts.
For the example the plant consists of one mains incomer, three generators and nine inverters.
Table 2.3
Example of power source data for plant
Power source Frequency [Hz] Voltage [V] Current [A] S [VA] PF P [kW] CT ratio PT ratio Amount
generator 1 50 400 625 0.8 500 1000/5 1:1
generator 2 50 400 625 0.8 500 1000/5 1:1
generator 3 50 400 480 0.8 384 1000/5 1:1
mains 50 400 600 480 1000/5 1:1
solar panel 0.265 2100
solar park 557
inverter size 60 9
inverter total 50 400 779 540 1000/5 1:1
COMMISSIONING GUIDELINES 4189341077D EN Page 8 of 58
