DEKA DURATION DD5300
41
Information: Connect the cables according to the installation requirements, always paying
attention to minimize the length of the cables to avoid voltage drops.
Attention: To ensure safety and stability of the cluster always connect the Battery Modules using the feet.
Attention:
Install the stackable flat front cover plate
to protect the bus bar and cables
BEFORE TURNING ON
Battery Modules installed correctly, see image below.
Suggested
Cable Output
from the
Upper Side
Attention: Illustrations shown are for reference only. Please always refer to the physical Battery Module in
front of you, and if the module has a different configuration to this manual, stop all activity immediately and
contact your Deka Duration technical service representative.
