Deka DURATION DD5300 - CAN Hub General System Description

DEKA DURATION DD5300
52
2.9.3 CAN Hub General System Description
CAN Hub is Mandatory for Multiple Cluster Installation
ATTENTION:
BEFORE PROCEEDING WITH THE DD22100 INSTALLATION IT IS MANDATORY TO READ THE INSTRUCTIONS BELOW
Special BUS Bar for Parallel Configuration
(MODULES INTERCONECTION BUS BAR MODEL – ACCESSORY)
ATTENTION: BUS BARS ARE MANDATORY FOR STACK SYSTEM.
ATTENTION: DO NOT USE DIFFERENT BUS BAR TYPES OR CABLES.
ATTENTION: EACH BATTERY MODULE AND EACH CLUSTER MUST HAVE THE SAME SoC% and VOLTAGE.
ALL THE BATTERY MODULES MUST HAVE THE SAME FIRMWARE.
