Deka DURATION DD5300 - Conceptual Diagram of a Cluster Composed by 5 Clusters and 8 Batteries each

DEKA DURATION DD5300
56
2.9.7 Conceptual Diagram of a Cluster composed of 5 clusters of 8 batteries each.
Note: It is possible to install up to 7 clusters composed of 15 batteries each for a total of 105 batteries.
SUB n
SUB 1
MASTER
CAN BMS
INVERTER CIRCUIT
BREAKER
Positive and Negative
(US market Only)
CLUSTER
CIRCUIT
BREAKER
POWER LINE MAX 60Vdc
CUSTER 01
CUSTER 02
CUSTER 03
CUSTER 04
CUSTER 05
