DEKA DURATION DD5300
48
Cable size verification for a cluster composed by 5 or more Battery Modules connected to the inverter
with 2 sets of cables (50mm² each) for a total of 100 mm² each terminal (positive and negative).
Numbers of Modules
C-Rate
Current Allowance
Power W
Capacity kWh
1
1
100
5.200
5.20
2
0.98
196
10.192
20.38
3
0.96
288
14.976
44.93
4
0.94
376
19.552
78.21
5
0.92
460
23.920
119.60
6
0.9
540
28.080
168.48
7
0.88
616
32.032
224.22
8
0.86
688
35.776
286.21
9
0.84
756
39.312
353.81
10
0.82
820
42.640
426.40
11
0.8
880
45.760
503.36
12
0.78
936
48.672
584.06
13
0.76
988
51.376
667.89
14
0.74
1036
53.872
754.21
15
0.72
1080
56.160
842.40
ATTENTION
The Battery Terminal Block can support max 50/75mm² on each connection point (two each pole).
It is compulsory to set the maximum inverter current in accordance with the output cables
capabilities.
A cable size calculator is available on www.mkbattery.com
ATTENTION
Cable sizing must be calculated by a qualified technician/engineer, based on local regulations,
and in accordance with overall system design.
