Delem
V0208, 2.43
Analog input signals
NCS NC Start Control is started.
EOS End Of Stroke Stroke is finished, either position is reached or
stroke time has elapsed
EOC End Of Cycle Program step is finished
F1 Function output 1 General purpose programmable output
F2 Function output 2 General purpose programmable output
F3 Function output 3 General purpose programmable output
F4 Function output 4 General purpose programmable output
SC0 Stock Counter 0 Stock counter has reached 0 after downcounting
B_UP Blade up Move blade up
B_DN Blade down Move blade down
CLAMP Clamping force Indicate clamping pressure is active
XSAFE X at safe position Indicate X-axis is outside safety zone
G2_OK Gap 2 OK Gap 2 control ready
G2_IP Gap 2 IP Gap 2 in position
G2+ Gap2 open Increase gap2 opening
G2- Gap2 close Reduce gap2 opening
G1_OK Gap 1 OK Gap 1 control ready
G1_IP Gap 1 in position Gap 1 in position
G1+ Gap open Increase gap opening
G1- Gap close Reduce gap opening
A_OK Angle control ready Angle control circuitry ready
A_IP Angle in position Blade has reached correct angle
A+ Angle increase Increase angle between table and shear
A- Angle decrease Reduce angle between table and shear
X_OK X-axis ready X-axis control ready
X_IP Backgauge in position X-axis has reached position
X++ Fast opening Fast opening command for AC motor X-axis
X+ Opening Opening command for AC motor X-axis
X- Closing Closing command for AC motor X-axis
X-- Fast closing Fast closing command for AC motor X-axis
BRK Brake (AC) Brake signal for AC motor, equipped with brake
system. This signal is ‘low-active’: during
positioning the signal is high, it will become low
when the brake must be applied.
Code Name Description
SFB Stroke Feedback Position feedback of the shear, in case Stroke
feedback is enabled.
