Delem
V0208, 2.49
4.4. Display codes
In the upper richt corner of the screen, a status code is shown that indicates the current status
of the control. Such a code can either be a status code or and error code.
The following table shows the possible status codes:
The following table shows the possible error codes:
(1) If this error occurs, reboot the control. If the error persists, contact your machine supplier.
S0 Stopped Waiting for the operator to press start while pump start is
high
S1 Positioning Not all axes are in position yet
S2 Wait for ST low Waiting for STEP input falling edge
S3 Wait for EOS Wait for EOS, generated by potentiometer or BR
S4 Wait for UDP Wait for UDP, generated by potentiometer or STEP input
S5 Wait for STEP high Waiting for STEP input rising edge
S6 Wait for end of retract Waiting for end of retract when STEP is already high.
S7 Wait for safe X Waiting until X-axis is in safe area
E1.. Internal error (1)
E21 Power supply failure
E23 Encoder 1 error
E24 Encoder 2 error
E53 Invalid parameters
E56 No movement on X-axis
E57 No movement on A-axis
E58 No movement on G1-axis
E59 No movement on G2-axis
E94 Internal error (1)
