Machine Characteristics
Bisky
Chapter 3 Machine Characteristics
3.1 Machine specifications
Machine dimensions and weight
Feeding data
Electrical plant
Machine dimensions and weight
Bisky - 400 Bisky - 460 Bisky - 600 U.M.
A 1570 1570 1570 mm
B 1196 1196 1196 mm
C 1032 1074 1232 mm
Total weight 300 325 350 Kg
Dough capacity 32 36 48 litri
Tension upon request
Frequency upon request
Total power (KW) installed 3 Kw
A
B
C
