Use
Bisky
Adjustment and replacement of the broken wire
To replace the wire proceed as follows : (The spare wire can be found in the machine tool
box).
1. Loosen as much as possible the two fixing nuts (1), these can be found on the two
wire tensioners in bronze.
2. Extract the steel wire (2) present.
3. Insert one of the edges of the new steel wire into the hole at the centre of the fixing
nut and refix the knob so as to anchor this edge.
4. Unloose the nut (7) located on the brass tension rod fastened on the external lever of
the device.
5. Insert the free edge of the wire in the holes of the wire cut devices levers.
6. Now insert the wire edge in the hole at the centre of the brass tension rod (6) making
sure that it comes out from the hole in the rear end of the tension rod (6). Turn the
wire clockwise under the washer fitted under the nut (5) and gently lock it in place.
7. Make sure that the wire is properly tensioned by tightening nut (4) first and nut (3)
after.
8. Whilst the wire is cutting, make sure that it is in perfect contact with the plastic
moulds.
NOTE This condition is important in order to obtain correct cutting results.
BEWARE In order to obtain the correct cutting of the biscuit the steel wire must be
tensioned correctly.
