Maintenance
Bisky
Cleaning of the wire cut plate
Fig. 7.2 Dismantling of the plate
Dismantling stages of the plate and its cleaning
1. Unscrew the nozzle fastening nuts (1).
2. Extract towards the Delrin template (2).
3. After having completely dismantled the plate, clean it and then reassemble the
whole by following the same procedure in the opposite order.
1
2
