Table 9. DD6800 with ES30 primary node cabling instructions (continued)
String
(
Loop)
I/O - Port Shelf Port Length
a
2 I/O 2 - Port 2
A controller HOST
port of the highest number shelf in V2
2M
3 I/O 7 - Port 1
B controller HOST
port of shelf V3.1
2M
3 I/O 2 - Port 1
A controller HOST port of the highest number shelf in V3
2M
4 I/O 7 - Port 3
B controller HOST port of shelf V4.1
3M
4 I/O 2 - Port 3
A controller HOST
port of the highest number shelf in V4
3M
a.
C
able lengths shown are designed for Data Domain racks. Longer cables (up to 5M) can be used.
Table 10. DD6800 with ES30 standby node cabling instructions
String
(Loop)
I/O - Port Shelf Port Length
a
1 I/O 7 - Port 0
A controller EXPANSION
port of shelf V1.1
2M
1 I/O 2 - Port 0
B controller EXPANSION port of the highest number shelf in V1
2M
2 I/O 7 - Port 2
A controller EXPANSION port of shelf V2.1
2M
2 I/O 2 - Port 2
B controller EXPANSION port of the highest number shelf in V2
2M
3 I/O 7 - Port 1
A controller EXPANSION port of shelf V3.1
2M
3 I/O 2 - Port 1
B controller EXPANSION port of the highest number shelf in V3
2M
4 I/O 7 - Port 3
A controller EXPANSION port of shelf V4.1
3M
4 I/O 2 - Port 3
B controller EXPANSION
port of the highest number shelf in V4
3M
a.
C
able lengths shown are designed for Data Domain racks. Longer cables (up to 5M) can be used.
52 Connect Cables and Power On
