Dell EMC Data Domain DD6800 User Manual

DD6800 with HA and DD Cloud Tier
Table 15. DD6800 with DS60 HA and DD Cloud Tier primary node cabling instructions
String
(
Loop)
I/O - Port Shelf Port Length
a
1 I/O 7 - Port 0 A controller port 0 of shelf V1.1 2M
1 I/O 2 - Port 0 B controller port 0 of the highest number shelf in V1 2M
2 I/O 7 - Port 2
A controller HOST
port of the second metadata shelf
2M
2 I/O 2 - Port 2
B controller HOST port of the first metadata shelf
2M
3 I/O 7 - Port 3
A controller HOST
port of the SSD shelf
2M
3 I/O 2 - Port 3
B controller HOST port of the SSD shelf
2M
a.
C
able lengths shown are designed for Data Domain racks. Longer cables (up to 5M) can be used.
Table 16. DD6800 with DS60 HA and DD Cloud Tier standby node cabling instructions
String
(Loop)
I/O - Port Shelf Port Length
a
1 I/O 7 - Port 0 B controller port 2 of shelf V1.1 2M
1 I/O 2 - Port 0 A controller port 2 of the highest number shelf in V1 2M
2 I/O 7 - Port 2
B controller EXPANSION
port of the second metadata shelf
2M
2 I/O 2 - Port 2
A controller EXPANSION port of the first metadata shelf
2M
3 I/O 7 - Port 3
A controller EXPANSION port of the SSD shelf
2M
3 I/O 2 - Port 3
B controller EXPANSION port of the SSD shelf
2M
a.
C
able lengths shown are designed for Data Domain racks. Longer cables (up to 5M) can be used.
Connect Cables and Power On 59
