Table 12. DD6800 with DS60 primary node cabling instructions (continued)
String
(
Loop)
I/O - Port Shelf Port Length
a
2 I/O 7 - Port 1 A controller port 0 of shelf V2.1 2M
2 I/O 2 - Port 1 B controller port 0 of the highest number shelf in V2 2M
3 I/O 7 - Port 2 A controller port 0 of shelf V3.1 2M
3 I/O 2 - Port 2 B controller port 0 of the highest number shelf in V3 2M
4 I/O 7 - Port 3
A controller HOST
port of the SSD shelf
2M
4 I/O 2 - Port 3
B controller HOST
port of the SSD shelf
2M
a.
C
able lengths shown are designed for Data Domain racks. Longer cables (up to 5M) can be used.
Table 13. DD6800 with DS60 standby node cabling instructions
String
(Loop)
I/O - Port Shelf Port Length
a
1 I/O 7 - Port 0 B controller port 2 of shelf V1.1 2M
1 I/O 2 - Port 0 A controller port 2 of the highest number shelf in V1 2M
2 I/O 7 - Port 1 B controller port 2 of shelf V2.1 2M
2 I/O 2 - Port 1 A controller port 2 of the highest number shelf in V2 2M
3 I/O 7 - Port 2 B controller port 2 of shelf V3.1 2M
3 I/O 2 - Port 2 A controller port 2 of the highest number shelf in V3 2M
4 I/O 7 - Port 3
A controller EXPANSION
port of the SSD shelf
2M
4 I/O 2 - Port 3
B controller EXPANSION port of the SSD shelf
2M
a.
C
able lengths shown are designed for Data Domain racks. Longer cables (up to 5M) can be used.
56 Connect Cables and Power On
