Dell EMC Data Domain DD6800 - DD6800 with ERSO; DD6800 with DS60 Shelves, HA and DD Cloud Tier; DD6800 with DS60 ERSO

Figure 54. DD6800 with DS60 shelves, HA and DD Cloud Tier
D
D6800 with ERSO
Table 17. DD6800 with DS60 ERSO
String
(
Loop)
I/O - Port Shelf Port Length
a
1 I/O 7 - Port 0 A controller port 0 of shelf V1.1 2M
1 I/O 2 - Port 0 B controller port 0 of the highest number shelf in V1 2M
2 I/O 7 - Port 1 A controller port 0 of shelf V2.1 2M
2 I/O 2 - Port 1 B controller port 0 of the highest number shelf in V2 2M
60 Connect Cables and Power On
