Power on all systems
NOTE:
Power on all expansion shelves first before powering on the controller.
1. C
onnect power cables to each expansion shelf receptacle and attach the retention clips.
2. Provide power to power on each expansion shelf. The shelves power on when plugged in. Ensure that each shelf power cable
is connected to a different power source.
NOTE:
Wait approximately 3 minutes after all expansion shelves are powered on before powering on the controller.
3. P
rovide power to power on the controller. The system powers on when plugged in. The first boot may take several minutes
to complete.
NOTE:
Connect systems to redundant AC power sources. Redundant power sources allow one AC source to fail or be
serviced without impacting system operation. PSU0 should be attached to one AC source. PSU1 should be attached to
the other AC source.
a. C
onnect power cables to each receptacle and attach the retention clips.
b. Ensure that each power supply is connected to a different power source.
Connect Cables and Power On 63
