LED Description
• Flashing yellow, 1 second on/o—Port beacon
NOTE: The rst QSFP28 LED shows 100GbE, 40GbE, or 10GbE mode. All four QSFP28 port LEDs show 4x25GbE or 4x10GbE
mode. The rst and third QSFP28 port LEDs show 2x50GbE mode.
Table 6. QSFP28 port LEDs—S5232F-ON, S5248F-ON, and S5296F-ON
LED Description
Link/Activity LED—100GbE, 40GbE, or 10GbE mode First LED:
• O—No link/activity
• Solid green—Port link operating at maximum speed, 100G
• Flashing green—Port activity operating at maximum speed,
100G
• Solid yellow—Port link operating at a lower speed, 40G or 10G
port
• Flashing yellow, ~30ms—Port activity operating at lower speed,
40G or 10G port
• Flashing yellow, ~1 second on/o—Port beacon
Link/Activity LED—4x25GbE or 4x10GbE mode
All four LEDs:
• O—No link/activity
• Solid green—Link operating at maximum speed, 4x25G port
• Flashing green—Link activity operating at maximum speed,
4x25G port
• Solid yellow—Link operating at a lower speed, 4x10G port
• Flashing yellow, ~30ms—Port activity operating at lower speed,
4x10G port
• Flashing yellow, 1 second on/o—Port beacon
Link/Activity LED—2x50G mode First and third LEDs:
• O—No link/activity
• Solid green—Port link operating 2x50G
• Flashing yellow—Port activity at 2x50G port
• Flashing yellow, 1 second on/o—Port beacon
Link/Activity LED—2x50GbE mode First, second, fth, and sixth LEDs"
• O—No link/activity
• Solid green—Port link operating 2x50G
• Flashing yellow—Port activity at 2x50G port
• Flashing yellow, 1 second on/o—Port beacon
Prerequisites
The following is a list of components required for successful switch installation:
NOTE
: For detailed installation instructions, see Site preparations and S5200F-ON Series switch installation.
• S5200F-ON Series (S5232F-ON, S5248F-ON, or S5296F-ON) switch or multiple switches, if stacking
• AC or DC country- and regional-specic cables to connect the AC or DC power source to each of the switches’ AC or DC power
supplies
16
S5200F-ON Series switch
