NOTE: For more installation instructions, see the installation labels attached to the rail assembly.
Figure 12. Separate rails
Tool-less square-hole installation
NOTE
: For more installation instructions, see the installation labels attached to the rail assembly.
NOTE: For S5296F-ON installation instructions, see S5296F-ON four-post rack assembly.
1 Place one rail between the left and right vertical posts with the ReadyRails ange ears facing outward. Align and seat the back ange
rail pegs in the back vertical post ange.
The following shows how the pegs appear in both the square and nonthreaded round holes:
S5200F-ON Series switch installation
25
