l
Configure Support Credentials, Customer Contact Information, and EMC
Secure Remote Services (recommended)
l
Configure iSCSI Interfaces (optional)
l
Set up a NAS Server (optional)
b. Enable SSH under Service > Service Tasks (recommended for remote
support)
c. Update system software under Settings > Software and Licenses (as
required)
d. Configure Block and File resources, and Hosts (as required)
3. Use this guide and the
Hardware Information Guide
to:
a. Rack and install optional DAEs
b. Cable the optional DAEs
c. Power up the optional DAEs
d. Configure extra Block and File resources, and Hosts (as required)
Site and equipment preparation
The following items are required for installation.
Tools: ESD protection kit, slotted or Phillips screwdriver (optional), and a mechanical
lift (optional).
Management console: A Windows-based computer to run the initialization,
maintenance, and management tools with:
l
At least 100 MB of free space
l
Connection on same LAN subnet as your storage system (recommended)
l
Web browser (Internet Explorer, Mozilla Firefox, Google Chrome)
Refer to the Unity Support Matrix on the support website for compatibility and
interoperability information related to the Web browsers.
Space: Cabinet vertical space of 2U (3.5 inches, 8.9 cm) for the disk processor
enclosure (DPE), and if applicable, the following cabinet space for each DAE:
l
2U, 25-drive DAE (3.4 inches, 8.63 cm)
l
3U, 15-drive DAE (5.75 inches, 14.6 cm)
Network connections: The following I/O modules and embedded modules are available
for network connectivity.
l
4-port 16Gb Fibre Channel I/O module
l
4-port 25GbE Optical I/O module
l
4-port 10GbE BaseT I/O module
l
4-port 12Gb SAS backend I/O module
l
10GbE BaseT 4-port card
l
25GbE 4-port card
Network information:
Installation Procedures
Site and equipment preparation 11
