25-drive DAE container contents
Verifying shipping package contents
Confirm that you received all necessary equipment needed to install the new 25-drive
DAE.
Verify that you received the following:
Component Quantity
Disk-array enclosure (25-
drive DAE)
Front view
Rear view
1
Rail kit, including
Snap-in rails (2)
Screws (3 per rail)
1
Power cords 2
Bezel for disk-array
enclosure (with key)
1
mini-SAS HD cables (either 1
meter or 2 meter copper)
that connect disk-array
enclosures to each other (1
meter cables) or to DPE (2
meter cables)
2
Installation Procedures
25-drive DAE container contents 27
