Back-end bus
and enclosure
number
Cable label
Expansion port cable labeling details Primary port cable labeling details
Label part
number
Label Port Label part
number
Label Port
BE4 enclosure 0
and above - A-
side
046-005-935
SP A A0 PORT 2
046-005-679_xx
SP A A0 PORT 2
SP A A0 PORT 2
SP A A0 PORT 2
SP A A0 PORT
2
046-021-020
LCC A Port A
046-021-020_xx
LCC A Port A
LCC A Port A
LCC A Port A
LCC A Port A
BE4 enclosure 0
and above - B-
side
046-005-937
SP B B0 PORT 2
046-005-718_xx
SP B B0 PORT 2
SP B B0 PORT 2
SP B B0 PORT 2
SP B B0 PORT
2
046-021-021
LCC B Port A
046-021-021_xx
LCC B Port A
LCC B Port A
LCC B Port A
LCC B Port A
BE5 enclosure 0
and above - A-
side
046-005-936
SP A A0 PORT 3
046-005-679_xx
SP A A0 PORT 3
SP A A0 PORT 3
SP A A0 PORT 3
SP A A0 PORT
3
046-021-022
LCC A Port A
046-021-022_xx
LCC A Port A
LCC A Port A
LCC A Port A
LCC A Port A
BE5 enclosure 0
and above - B-
side
046-005-938
SP B B0 PORT 3
046-005-718_xx
SP B B0 PORT 3
SP B B0 PORT 3
SP B B0 PORT 3
SP B B0 PORT
3
046-021-023
LCC B Port A
046-021-023_xx
LCC B Port A
LCC B Port A
LCC B Port A
LCC B Port A
b. For SP A, connect the DAE cable to the lowest available port in the SAS
module in the bottom storage processor of the DPE to port A on link control
card AA/A (LCC A) on the right side of the DAE.
c. For SP B, connect the DAE cable to the lowest available port in the SAS
module in the top storage processor of the DPE to port A on link control card
BB/B (LCC B) on the left side of the DAE.
Field Upgrade Procedure
34 Unity All Flash and Unity Hybrid Field Upgrade Procedure
To Next Page
