Dell 1135N - Page 36

Product specification and feature
2-24
Service Manual
ଝ AC Input
Input Rated Voltage AC 220V ~ 240V AC 110V ~ 127V
Input Voltage fluctuating range AC 180V ~ 270V AC 90V ~ 135V
Rated Frequency 50/60 Hz
Frequency Fluctuating range 47 ~ 63 Hz
Input Current
Under 4.0Arms / 2.0Arms (But, the status when e-coil is off or
rated voltage is inputted/outputted )
ଝ Rated Output Power
NO ITEM CH1 CH2 Remark
1 CHANNEL NAME +5.0V +24.0V
2 CONNECTOR PIN
CON 14
5V PIN : 7,15,16
GND PIN : 4,8,13,14
CON 14
24V PIN : 5,6
GND PIN : 4,8,13,14
CON 14
24VS PIN : 9,10,11
3 Rated Output
+5.1V ± 5%
(4.845 ~ 5.355V)
+24V ± 10%
(21.6 ~ 26.4V)
4 Max. Output Current 1.0 A 2.0 A
Peak Loading Current 1.2 A 2.3 A
6 RIPPLE NOISE Voltage Under 100mVp-p Under 500mVp-p
7 Normal output 5.0W 43.2W
8 Maximum output 6.0W 55.2W
9
Protection for loading
shortage and overflowing
current
Shut down or Fuse
Protection
(Under LPS spec)
Shut down(2.8A~4.5A) or
Voltage Drop(tnip-10%)
■ SMPS Board
