Disassembly and reassembly
Figure 28. Connecting the lightbar cables
Steps
1. Lift the metal shield partially and connect the display cable to the connector on the display panel.
2. Align the screw holes on the metal shield to the screw holes on the display panel.
3. Replace the three screws (M3x4) to secure the metal shield to the display panel.
4. Connect the lightbar cables to the connectors on the display panel.
5. Adhere the tapes to secure the lightbar cables and metal shield to the display panel.
Next steps
1. Install the speaker.
2. Install the back cover.
3. Install the stand.
4. Follow the procedure in After working inside your monitor.
