Views of S3225QS monitor
Bottom view
Figure 4. Bottom view of the monitor
Table 3. Bottom view descriptions.
No. Description Use
1
HDMI 2 port
Connect your computer with the HDMI cable shipped with your monitor.
2
HDMI 1 port
Connect your computer with the HDMI cable shipped with your monitor.
3
DisplayPort
Connect your computer with the DisplayPort cable (purchased
separately).
4
Stand-lock feature Lock the stand to the monitor using a M3 x 6 mm screw (screw not
included).
5
Security-lock slot
(based on Kensington Security Slot)
Secure your monitor using a security lock (purchased separately) to
prevent unauthorized movement of your monitor.
6
Power connector
Connect the power cable (shipped with your monitor).
7
Built-in speakers Provides audio output.
