Diagnostic aids 3-17
Diagnostics menu
Entering Diagnostics menu
1. Turn off the printer.
2. Press and hold 3 and 6.
3. Turn on the printer.
4. Release the buttons after ten seconds.
Available tests
The tests display on the operator panel in the order shown:
Note: Menus may vary depending on the features and options of the printer.
Registration See “Registration (printer)” on page 3-18.
Print tests See “Print Tests” on page 3-20.
Hardware tests See “Hardware Tests” on page 3-21.
Duplex tests See “Duplex Tests” on page 3-24.
Input Tray Tests See “Input Tray Tests” on page 3-26.
Output Bin Tests See “Output bin tests” on page 3-27.
Base Sensor Test See “Base Sensor Test” on page 3-28.
Device Tests See “DEVICE TESTS” on page 3-28
Printer setup See “PRINTER SETUP” on page 3-29.
EP Setup See “EP SETUP” on page 3-31.
Reports See “Reports” on page 3-32.
Event Log See “Reports” on page 3-32.
Scanner Tests See “Scanner Tests” on page 3-34
Exit Diagnostics See “Exit Diagnostics” on page 3-37.
