Dell 3335dn Service Manual

Repair information 4-79
Toner level sensor removal
1. Open the front access door.
2. Remove the right side cover. See “Right side cover removal” on page 4-77.
3. Disconnect the toner level sensor cable (A) from the engine board.
4. Squeeze the lower tabs (B) of the toner level sensor, and push it from its holder.
5. Remove the toner level sensor through the inside of the printer.
Note: The toner level sensor must be installed properly, or the printer will not function.
AB
