1-2 Service Manual
Print engine specifications
Memory
Print quality settings
Item
Standard memory 128MB 128MB
Maximum memory 640MB 640MB
Optional memory
128MB DDR SDRAM unbuffered DIMMS ✔✔
256MB DDR SDRAM unbuffered DIMMS ✔✔
512MB DDR SDRAM unbuffered DIMMS ✔✔
Optional flash memory
256 MB via flash memory card ✔✔
Optional font cards (DBCS) ✔✔
Option slots
ISP (INA) slot 1 1
Memory slots 1 1
Flash memory/option card 2¹ 2¹
¹ Both slots are active for either a 256MB Flash memory card, a font card, or a DLE. Multiple Flash, font, or DLE cards
are not supported.
Item
Print resolution
1200 Image quality¹ ✔✔
2400 Image quality² ✔✔
600 X 600 dpi ✔✔
1200 X 1200 dpi³ ✔✔
¹ 1200 Image quality is defined as 600 dpi with 2 bit IET (Image Technology) default mode for all models.
² 2400 Image quality is defined as 600 dpi with 4 bit IET.
³ True 1200 dpi at 1/2 the rated speed
X463, X464 / 3333dn, 3335dn X466
X463, X464 / 3333dn, 3335dn X466
