Dell 3335dn - Left Rear Frame Assembly Removal

4-68
Left rear frame assembly removal
1. Remove the flatbed assembly. See “Flatbed removal” on page 4-86.
2. Remove the three screws (A) from the left rear frame assembly.
3. Carefully lift the left rear frame assembly off of the print engine frame.
A
A
A
A
