Dell 3335dn - Fan Removal

4-24
Fan removal
1. Remove the right side cover. See “Right side cover removal” on page 4-77.
2. Disconnect the cable (A) from the engine board, and remove the two screws (B) holding the fan to the right
side frame.
3. Remove the fan.
BA
