Diagnostics information 2-3
Printer symptom table
Symptom Action
Touchscreen displays upside down Replace the display keypad.
Fan noisy or fan not working. See “Cooling fan service check” on page 2-37.
Fuser parts melted. See “LVPS/HVPS service check” on page 2-39.
Toner not fused to the media. See“Fuser service check” on page 2-39 or “Solving print
quality problems” on page 2-51.
Paper jams. See “Paper feed service checks” on page 2-43.
Main motor noisy or not moving. See “Main motor service check” on page 2-40.
Media skew. See “Paper feed service checks” on page 2-43.
Printer not communicating with host. See “USB port service check” on page 2-46.
Card reader fails to recognize the user’s security
card. (Possible card reader failure)
See “Card reader service check” on page 2-37.
Front access door will not close. See “Cover interlock switch service check” on page 2-37.
Operator panel button not responding. See “Operator panel service check” on page 2-43.
Operator panel lights are off or very dim. See “Operator panel service check” on page 2-43.
Blank page. See “Blank page” on page 2-47.
Black page. See “Black page” on page 2-48.
Heavy background. See “Heavy background” on page 2-48.
Light print. See “Light print” on page 2-50.
White or black lines or bands. See “White or black lines or bands” on page 2-50.
Toner on back of page. See “Toner on back of page” on page 2-50.
Media never picks. See “Media never picks” on page 2-44.
Media feeds continuously. See “Media occasionally mispicks or picks multiple sheets
at once” on page 2-44.
Media wrinkled or bent. See “Media “trees,” wrinkles, stacks poorly, or curls” on
page 2-45.
Dead machine (no power). See “Dead machine service check” on page 2-38.
Print quality problems
• Light print
• Blurred characters
• Toner on both sides of media
• Toner not fused
• Streaks
• Blank pages
See “Solving print quality problems” on page 2-51.
