1-4 Dell PowerEdge 6100/200 System Service Manual
Figure 1-3. Front/Left Internal View
external drive
bay (4)
internal drive
bay (6)
control panel
support panel
memory module
air intake panel
(cooling fans are
located behind the
air intake panel)
hard-disk drive
security lock
expansion slot (10)
system board
secondary microprocessor
module or terminator
module
primary
microprocessor
module
