Removing the Display Mini-Card Cable | 112
Procedure
1 Remove the screw that secures the display mini-card cable to the display back-cover.
2 Peel off the display mini-card cable from the display back-cover.
3 Lift the display mini-card cable off the display back-cover.
1display mini-card cable 2screw
3 display back-cover
