Removing the Display Mini-Card | 76
Procedure
1 Lift the latch and disconnect the display mini-card cable from the display mini-card.
2 Remove the screw that secures the display mini-card to the system board.
3 Slide and remove the display mini-card from the mini-card connector.
1 display mini-card cable 2 latch
3 display mini-card 4 mini-card connector
5screw
