Removing the Media-Card Reader | 73
Procedure
1 Lift the latches and disconnect the status-light cable and the media-card reader
cable from the media-card reader.
2 Remove the screws that secure the media-card reader to the computer base.
3 Lift the media-card reader off the computer base.
1 status-light cable 2 media-card reader cable
3 latches (2) 4 media-card reader
5screws (3)
