Removing the Display-Light Boards | 115
Procedure
1 Peel the Mylar tapes that cover the display-light boards.
2 Remove the screws that secure the display-light boards to the display back-cover.
3 Lift the display-light boards off the display back-cover.
1 display back-cover 2 Mylar tapes
1 display-light boards (3) 2 screws (3)
book.book Page 115 Friday, June 28, 2013 3:27 PM
