Removing the Display Assembly | 96
Procedure
1 Disconnect the antenna cables from the wireless mini-card.
2 Remove the screws that secure the display assembly to the computer base.
3 Note the antenna cables routings and remove the cables from their routing guides.
1 screws (4) 2 computer base
3 antenna cables routing guide 4 antenna cable(s)(3)
book.book Page 96 Friday, June 28, 2013 3:27 PM
