Removing the Display Assembly | 97
4 Turn the computer over and open the display as far as possible.
5 Disconnect the display cable, display mini-card cable, and display-light board cable
from the system board.
6 Remove the cables from their routing guides.
7 Remove the screws that secure the display assembly to the computer base.
8 Lift the display assembly off the computer base.
1 screws (3) 2 display-light board cable
3 display cable 4 latch
5display mini-card cable
book.book Page 97 Friday, June 28, 2013 3:27 PM
