Removing the Secondary Hard Drive | 25
5 Disconnect the interposer from the hard drive.
6 Remove the screws that secure the hard-drive bracket to the hard drive.
7 Lift the hard-drive bracket off the hard drive.
1hard-drive bracket 2 screws (4)
3 hard drive 4 interposer
1
2
3
4
