Removing the Keyboard | 55
6 Lift the latch and disconnect the keyboard cable from the keyboard daughter board.
7 Lift the keyboard at an angle and release it from the tabs on the palm-rest assembly.
1tabs 2keyboard
3 latch 4 keyboard cable
5screws (2)
1
2
5
4
3
