Table 1. Screw list(continued)
Component Secured to Screw type Quantity Screw image
Heat-sink assembly Palm-rest assembly M2.5x5 2
Per key keyboard Palm-rest assembly M1.2x2.5 57
Hard-drive assembly Palm-rest assembly M2x3 4
Hard-drive bracket Hard drive M3x3 4
Power-adapter port
bracket
Palm-rest assembly M2x3 1
Rear-I/O cover Computer base M2.5x2.5 4
Rear-I/O cover Palm-rest assembly M2.5x7 2
System board Palm-rest assembly M2.5x5 4
M.2 2280 solid-state
drive in M.2 slot one
Palm-rest assembly M2x3 1
M.2 2280 solid-state
drive in M.2 slot two
Palm-rest assembly M2x3 1
M.2 2230 solid-state
drive in M.2 slot one
Palm-rest assembly M2x3 2
M.2 2230 solid-state
drive in M.2 slot two
Palm-rest assembly M2x3 2
Solid-state drive
mounting bracket
Palm-rest assembly M2x3 2
M.2 2280 solid-state
drive in M.2 slot three
Solid-state drive
interposer board
M2x3 2
M.2 2280 solid-state
drive in M.2 slot four
Solid-state drive
interposer board
M2x3 2
Solid-state drive
interposer board
Solid-state drive
interposer board bracket
M2x3 3
Solid-state drive
interposer board
Palm-rest assembly M2x3 4
Card-reader board Palm-rest assembly M2.5x2.5 3
Touchpad bracket Palm-rest assembly M2x3 5
Wireless-card bracket System board M2x3 1
