Steps
1. Place the card-reader board in the slot on the palm-rest assembly.
2. Align the screw holes on the card-reader board with the screws holes on the palm-rest assembly.
3. Replace the three screws (M2.5x2.5) that secure the card-reader board to the palm-rest assembly.
4. Route the card-reader board cable through the routing guides on the computer base.
5. Connect the card-reader board cable to the system board.
Next steps
1. Install the
computer base.
2. Install the rear-I/O cover.
3. Install the
solid-state drive in M.2 slot two.
4. Install the wireless card.
5. Install the battery.
6. Install the base cover.
7. Follow the procedure in After working inside your computer.
Coin-cell battery
Removing the coin-cell battery
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the battery.
4. Remove the
solid-state drive from M.2 slot two.
5. Remove the card-reader board.
About this task
The following image indicates the location of the coin-cell battery and provides a visual representation of the removal procedure.
