Steps
1. Align the screw holes on the battery with the screw holes on the palm-rest assembly.
2. Replace the six screws (M2.5x5) that secure the battery to the palm-rest assembly.
3. Route the battery cable through the routing guides on the computer base and connect the battery cable to the system board.
Next steps
1. Install the
base cover.
2. Follow the procedure in After working inside your computer.
Memory modules
Removing the memory modules
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
About this task
The following image indicates the location of the memory modules and provides a visual representation of the removal procedure.
