Dell Alienware Area-51m R2 - Installing the Coin-Cell Battery; Computer Base; Removing the Computer Base

Steps
1. Adhere the coin-cell battery to the slot on the palm-rest assembly.
2. Connect the coin-cell battery to the system board.
Next steps
1. Install the card-reader board.
2. Install the solid-state drive in M.2 slot two.
3. Install the
battery.
4. Install the base cover.
5. Follow the procedure in After working inside your computer.
Computer base
Removing the computer base
Prerequisites
1. Follow the procedure in
Before working inside your computer.
2. Remove the
base cover.
3. Remove the battery.
4. Remove the wireless card.
5. Remove the solid-state drive from M.2 slot one.
6. Remove the
rear-I/O cover.
About this task
The following image indicates the location of the computer base and provides a visual representation of the removal procedure.
