Next steps
1. Install the base cover.
2. Follow the procedure in After working inside your computer.
Rear-I/O cover
Removing the rear-I/O cover
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
About this task
The following image indicates the location of the rear-I/O cover and provides a visual representation of the removal procedure.
Steps
1. Remove the two screws (M2.5x7) that secure the rear-I/O cover to the palm-rest assembly.
2. Disconnect the tron-light cable from the system board and peel it off from the computer base.
37
