Table 14. Screw listî(continued)
Component Screw type Quantity Screw image
Power-supply unit (for
computers shipped with clear
left-side cover)
#6-32x1/4" 4
Radiator and fan assembly for
liquid cooler
M3x5 2
Rear-chassis fan M3x5 1
Lower front-chassis fan M3x5 1
Solid-state drive (M.2 slot one/
slot two)
M2x3 1
Wireless card M2x3 1
System board #6-32x1/4" 9
Front I/O bracket #6-32x1/4" 1
Liquid-cooling assembly fan #6-32x1/4" 8
29
