Installing the antenna
About this task
This computer is shipped with an external puck antenna. Connect the external antenna during setup, to connect to WiFi and
Bluetooth and improve the memory performance. To connect the SMA cables, follow the below procedure.
Steps
1. Align and connect the SMA cables to the SMA connectors on the chassis.
2. Tighten the bolts to secure the SMA cables to the SMA connectors on the chassis to connect the external antenna to the
computer.
Next steps
1. Follow the procedure in
After working inside your computer.
Left-side cover
Removing the left-side cover
Prerequisites
1. Follow the procedure in Before working inside your computer.
About this task
The following images indicate the location of the left-side cover and provide a visual representation of the removal procedure.
NOTE: The clear left-side cover is shipped with some computers.
36
