5. Push the tab to release the lower front-chassis fan from the chassis.
6. Slide and lift the lower front-chassis fan off the chassis.
Installing the lower front-chassis fan
CAUTION: The information in this installation section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the lower front-chassis fan and provide a visual representation of the installation
procedure.
64
