2. Route the front I/O-panel cable through the slot on the front panel.
3. Push the front bezel towards the front panel and ensure the tabs clip on to the slots of the front panel.
NOTE: Start with tab on top, proceed to the tabs on the left of the front bezel, and then to the tabs on the right of the front
bezel.
4. Replace the four screws (#6-32x1/4") that secures the front bezel to the front panel.
5. Connect the front I/O-panel cable to the system board.
Next steps
1. Install the
right-side cover.
2. Install the left-side cover.
3. Follow the procedure in
After working inside your computer.
Top cover
Removing the top cover
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the left-side cover.
3. Remove the right-side cover.
4. Remove the front bezel.
About this task
The following images indicate the location of the top cover and provide a visual representation of the removal procedure.
43
