Hard Drive(s) 21
7
Remove the four screws that secure the hard drive to the hard-drive
bracket.
8
Lift the hard-drive off the hard-drive bracket.
9
Remove the interposer from the hard drive.
1 captive screws (3) 2 secondary hard-drive assembly
1
2
